$2,880.00 exl. GST
Zeus Remco Smooth Flow 14gpm – 53lpm 24v
Description
Zeus is the evolution the SoftWash industry has been asking for. Higher flow, higher pressure, and higher reach
12 VDC, 24 VDC, AND 115 VAC BYPASS OR ON DEMAND PRESSURE CONTROL
BULK AND INDIVIDUAL PACKAGING AVAILABLE CONSULT FACTORY FOR CONFIGURATIONS
90 Day Commercial Warranty
DOWNLOAD MANUAL
1” FNPT PORTS
10 AWG 12” WIRE LEADS FOR 12/24 VDC
6’ CORD AND PLUG FOR 115 VAC
VERTICAL SELF-PRIMING UP TO 14FT
140°F (60°C) MAX LIQUID TEMPERATURE
180°F (82°C) MAX MOTOR SHELL TEMPERATURE
DRY RUN CAPABILITY
100% FACTORY TESTED PERFORMANCE
HEAVY DUTY FAN COOLED MOTOR
STANDARD MOUNTING BASE WITH RUBBER GROMMETS
ALUMINUM HEATSINK FOR BETTER HEAT DISSIPATION
AG AND INDUSTRIAL SPRAYING
(COMPATIBLE WITH MOST COMMON CHEMICALS)
FERTILIZER APPLICATIONS
ROAD MAINTENANCE
WASHDOWN AND DUST SUPPRESSION
LIQUID DEICING APPLICATIONS
| Item Number | Flow | Controls | Pressure | Ports | Voltage | Spec Sheets |
|---|---|---|---|---|---|---|
90 day commercial warranty
Zeus Remco Bench Test Procedure- RESETTING THE PUMP
SMOOTHFLO PUMP SETTING
A GOOD PRESSURE GAUGE NEEDED THAT GOES TO AT LEAST 150PSI AND WOULD BE INSTALLED ON THE OUTLET SIDE OF THE PUMP INLINE.
TOOLS NEEDED- ONE ALLEN WRENCH THAT IS 1/16 AND THE BYPASS SET SCREW IS 3/32 WRENCH
5917-9I1-63B OR 90-5917-9I1-63B-SB
5918-9I1-94A OR 90-5918-9I1-94A-SB
- Step one run the pressure switch set screw in clockwise so that the pressure gauge reads 130psi.
- Step two run the bypass set screw in clockwise until pressure gauge reads 120psi.
- Step three back out (counterclockwise) the pressure switch set screw so it reads 110psi on the pressure gauge.
ZEUS = 160 for bypass and 138 for demand
Turn demand to 175ish then set bypass to 160 then turn down demand to 138
